R32 Self Drilling Anchor Bolt Anchor Bar Soil Nailing Rock Bolt Installation Procedure

R32 Self Drilling Anchor Bolt Anchor Bar Soil Nailing Rock Bolt Installation Procedure


SizeO.D(mm)I.D(mm)Ultimate Load(KN)Yield Load(KN)Weight(kg/meter)
R25N-14 25.014.02001502.3
R32L-2232.0 22.0  210 160 2.8
R32N-2132.0 21.0  280 230 2.9
R32N-18.532.0 18.5  280 2303.4
R32S-17.532.0 17.5360280 3.5
R32S-1532.0 15.0 360 280 4.1
R32SS-1432.0 14.0  450 3504.3
R38N-213.8021.0 500 400  4.8
R38N-1938.0 19.0 500400 5.5
R38S-1838.0 18.0 560 4606.0
R51L-3851.038.0550 450 6.0
R51L-3651.0 36.0 550450 7.6
R51N-3651.0 36.0 8006307.6
R51N-3351.0 33.0 800 630 8.4
R51S-3051.0 30.0930 730 9.4
T76N-4976.0 49.0 1600120016.5
T76S-4576.0 45.0 1900 1500 19.0
T30-1130.011.0 320260 3.3
T30-1430.0 14.0275 2202.9
T30-1630.0 16.0 245190 2.7
T40-1640.016.0 6605257.1
T40-2040.0 20.0 540 4255.6
T52-2652.026.0 930 730 10
T73-5673.0 56.0103583010.8
T73-5373.0 53.0 1160 97014
T73-4573.045.0 1600127017.5
T103-78103.0 78.0 22701800 25
T103-51103.0 51.03600267044
Thread directionLeft hand / Right hand
Thread standardISO 10208 / ISO1720 / Other international standards












PRODUCTS DETAILS

1. Competitive price and quality from our own factory
2. Approved by ISO9001, CE, SGS every year
3. Best service with 24 hour`s reply
4. Flexible payment with T/T,L/C , paypal, kunlun bank, etc
5. Quick delivery and standard exporting package
6. OEM/ODM
7.Email:sale@jssssteel.com
